The “Mechanical Construction and Factory” group within the “Electronics for NDT Systems” department has the following competencies:

  • Design and concept creation
  • Mechanical prototype development
  • Mechanical design (CAD – SOLIDWORKS 2017 and 2019)
  • Mechanical manufacture (CAM – FeatureCAM 2019)
  • Manufacture planning
  • Cutting machine operator apprenticeship

Machinery and equipment

  • CNC five-axis simultaneous milling machines and swivel rotary table (DMU 75 monoBlock)
Working area  x = 750 mm
 y = 650 mm
 z = 560 mm
Control Heidenhain TNC 640
Year of construction
2017



  • CNC five-axis milling machine (DMU 60 T)
Working area x = 630 mm
y = 560 mm
z = 560 mm
Control Heidenhain TNC 530
Year of construction
2002



  • Conventional milling machine (Maho 800)
Working area x = 700 mm
y = 400 mm
z = 450 mm
Year of construction
1973



  • CNC turning and milling machine (CTX Beta 800)
Max. work piece length with tailstock   x = 800 mm
Max. turning diameter   d = 410 mm
Control Siemens 840 D
Year of construction 2011



  • Servo engine lathe (Weiler C30)
Distance between centres
x = 750 mm
Max. turning diameter
d = 320 mm
Control Siemens 840 D
Year of construction 2013



  • Tool presetter (DMG UNO 20/40)
Measuring range
z = 400 mm
x = 400 mm (Ø)



  • Other machines and equipments
    • Sandblast cabin
    • Wig welding machine
    • Guillotine shears
    • Metal bandsaw (for 600 mm tensioning)
    • Bandsaw
    • Various free-standing machines and bench drills
